ARE-310 Planetary Paste Mixer |
|
| Dimensions |
|
H390 x W300 x D340 (mm) |
|
| Unit weight |
|
Approx. 21 kg |
|
| Maximum capacity |
|
310 g |
|
| Memory |
|
10 Memories
- STD Mode : 5 memories with 1 step
- STEP Mode : 5 memories with 5 steps
5 Memories (Each memory holds 5 sequential time and RPM steps) |
|
| Operating environment |
|
10 ~ 35 ℃, 35 ~ 85 % RH (Non-condensation) |
|
| System |
|
Planetary propeller-less mixing system |
|
| Maximum mixing weight |
|
250 g (NET) |
|
| Timer setting range |
|
0 s to 30 min in 1 s increments |
|
| Upper limit using a 300 ㎖ container |
|
250 ㎖, 250 g (NET) 250 ㎖, 310 g (Gross) |
|
| Revolution speed (Mixing mode) |
|
Mixing mode : Max. 2,000 RPM
- STD : Fixed 2,000 RPM,
- STEP : 0 RPM, 200 ~ 2,000 RPM,
Defoaming mode : Max. 2,200 RPM,
- STD : Fixed 2,200 RPM,
- STEP : 0 RPM, 400 ~ 2,200 RPM |
|
| Rotation speed (Mixing mode) |
|
Mixing mode : Max. 800 RPM follows 1/2.5 of revolution speed
Defoaming mode : Max. 60 RPM follows 1/36.7 of revolution speed |
|
| Safety features |
|
Lid locking sensor, Lid sensor, Vibration sensor, Speed sensor |
|
| Operating condition |
|
Indoor use only,
Elevation value within 2,000 m,
Pollution degree 2 |
|
| Power Supply |
|
Single Phase : AC100V +/-10, 50Hz/60Hz
Power Consumption :
- Standby : approx. 50VA
- Operating : max. 900VA |
|
|
